Sikaflex® TS Plus

• Chemical Resistance liquid manure, Sikaflex TS Plus, SKZ, Report No 69298/05-I
• Chemical Resistance silage liquids, Sikaflex TS Plus, SKZ, Report No 69298/05-II
• Migration Behaviour EN 1186, EN 13130, CEN/TS 14234, Sikaflex® TS Plus, ISEGA, Certificate No. 46763 U 18
• Sewage Installations waste water, Sikaflex TS Plus, SKZ, Report No 36142/98
• Silage Sikaflex TS Plus, DIBt, national technical approval No II 71-1.74.62-40/17

Polyurethane

12 months from date of production

The product must be stored in original, unopened and undamaged sealed packaging in dry conditions at temperatures between +5 °C and +25 °C. Always refer to packaging.

Resistant to many chemicals. Contact Sika Technical Services for additional information.

Note: The designer of the process system must be aware that all applications, including mesophilic and thermophilic digestion, are dependent on pH and content analysis which must be addressed at the specification phase.

*  Continuous maximum service temperatures are subject to the behaviour of chemical mixtures, which can be complex. The designer of the process system must be aware that all applications, including mesophilic and thermophilic digestion, are dependent on pH and content analysis which must be addressed at the specification phase.

The joint dimensions must be designed to suit the movement capability of the sealant.

The sealant must only be subjected to stress and chemical exposure after full curing to prevent reducing adhesion and performance.

Use closed cell, polyethylene foam backing rod.

+5 °C min. / +40 °C max.

+5 °C min. / +40 °C max.

min. +3 °C above dew point temperature

The substrate must be clean, dry, sound and homogeneous, free from oils, grease, dust and loose or friable particles.

For optimum adhesion and joint durability, the following substrate priming (and/or pre-treatment) procedures must be followed:

Non-porous substrates
Enamelled  steel, aluminium, anodised aluminium, stainless steel, galvanised steel, powder coated metals or glazed tiles. Slightly roughen surface with a fine abrasive pad. Clean and pre-treat using Sika® Aktivator-205 applied with a clean cloth.

Before sealing, allow a waiting time of > 15 minutes (< 6 hours).

Consult the tank manufacturer's instructions for their specific preparation and priming recommendations.

Other metals, such as copper, brass and titanium-zinc, clean and pre-treat using Sika® Aktivator-205 applied with a clean cloth. After a waiting time of > 15 minutes (< 6 hours). Apply Sika® Primer-3 N applied by brush. Before sealing, allow a waiting time of > 30 minutes (< 8 hours)

PVC has to be cleaned and pre-treated using Sika® Primer-215 applied with a brush. Before sealing, allow a waiting time of > 30 minutes (< 8 hours).

Porous substrates

Concrete, aerated concrete and cement based renders, mortars and bricks surfaces must be primed using Sika® Primer-3 N applied by brush.

Before sealing, allow a waiting time of > 30 minutes (< 8 hours).

Adhesion tests on project specific substrates must be performed and procedures agreed with all parties before full project application.

Note: Primers and activators are adhesion promoters and not an alternative to improve poor preparation / cleaning of the joint surface. Primers also improve the long term adhesion performance of the sealed joint.

Contact Sika Technical Services for additional information.

Clean all tools and application equipment immediately after use with Sika® Thinner C. Hardened material can only be removed mechanically. For cleaning skin, use Sika® Cleaning Wipes-100.
